T Solt Industrial Aluminium Profile System Assembly Production Line
for Industry
| Item | Aluminium extrusion profile for Industrial assembly production line |
| Material | Aluminium 6000 series alloy, such as 6061, 6063, 6082 etc. |
| Temper | T4, T5, T6 ,T66 |
| Thickness | General profile thickness:0.8-5.0mm; Anodized protection thickness:
8-25um; Powder coating color thickness: 40-120um. |
| Size | 3m-6m per piece, or customized. |
| Shape | Square, flat, round, hollow, oval, triangle, U-profile, L-profile,
T-profile, H-profile, customized available. |
| Surface Treatment | Mill-finish, anodized, powder coated, electrophoresis, wood grain,
timber, PVDF paint, polishing, brushed. |
| Color | Silver, champagne, black, bronze, gold, white or customized |
| Application | Window and door with thermal break strips, curtain wall, glass
wall, furniture, ceiling, kitchen, LED strip, transportation rail,
vehicle, motor housing, machine, tent, solar panel, industrial
profile, decoration profile etc. |
| Deep Process | CNC, drilling, milling, cutting, tapping, welding, bending,
assembling. |
| MOQ | 500 kgs for each item, usually 13-15 tons for a 20GP, 25-28 tons
for a 40HQ. |
| OEM service | Drawing, sample or design service offer by customer. |
| Production Capacity | 2400-3000 Metric tons monthly. |
| Brand Name | Hentec |
| Certificatesand Standard | ISO9001-2008 |
| Guarantee | Surface color can be stable for 10-20 years indoor using. |
| Packing Details | Inside: pack with plastic protective film to protect each piece. |
| Outside: wrap to bundle by waterproof craft paper or EPE film, or
customized |
| Delivery time | Die developing and sample testing: 12-18 days . |
| Mass production: 25-30 days after confirming sample by buyer. |
| FOB Port | Shanghai |
| Payment Terms | T/T 30% for deposit, balance after the copy of BOL . |
| Settlement Terms | Charge by final actual weight or by drawing theoretical weight. |
Description:
1. Material: 6063,6061,6060,6005,6005A,etc.
2. Temper: T5 or T6
3. Finish: Mill finish, anodizing, powder coating, electrophoresis,
wooden transfer or pvdf/carbon-flouride coated, polishing,
brushing, sand blasting
4. Various colors: Silver, bronze, black, gold, blue,grey,
champagne, bright, etc.
5. Machining: Cutting, punching, drilling, tapping, milling,
bending, welding, CNC etc.
6. Various in styles and sizes:
A) Aluminum alloy bars: 6000 series, normal material such as
6063,6005,6061,6060, special materials such as 6082 etc.
B) Aluminum profiles:
---General aluminum profiles (various shapes of pipes/tubes,
angles, T or U shapes etc.)
--- Industrial aluminum profiles ( TV frames, Rim for bicycles and
motorcycles, Heat sink profiles, Furniture, Ladder, Guide Rail,
Leisure materials, Shower Room, Solar Module Frame, Motor Shell,
Pipeline Integration etc.)
--- Construction aluminum profiles ( Aluminum doors& windows,
Sliding Windows, JB50A Door Window, Curtain Wall Frame etc.)
7. Certification: ISO9001,SGS,ROHS,TUV
8. Strong technical development ability, can provide high intensity
and high ductility aluminum profiles, to meet customers' different
requirements.
9. OEM service available, customized design available
10. Surface available: Mill finish, Anodized, Powder Coating,
Wooden transfering, electrophoresis, heat insulation, PVDF, and
deep processing
11. Certificate: ISO9001, ISO14001
Applications:
Industry Aluminum profile used in cars, trains machinery
,electronics, medical and other industrial filed . In terms of
hardware, machinery, electromechanical parts, solar PV products,
aluminum frames are adopt as important auxiliary materials. We also
have aluminum profiles for radiators, fitness machinery, buildings,
lighting instrument, windpipes, oil pipelines, for instance.
Specifications:
1.Primary Technical Data
1)Chemical composition
Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Impurity | Al |
6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.15 | Rest |
6060 | 0.3-0.6 | 0.1-0.3 | 0.1 | 0.1 | 0.35-0.6 | - | 0.15 | 0.1 | 0.15 | Rest |
6005 | 0.6-0.9 | 0.35 | 0.1 | 0.1 | 0.40-0.6 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
2)Mechanical property
Alloy | Temper | Tensile strength | Yield strength | Elongation |
6063 | T5 | ≥ 160Mpa | ≥ 110Mpa | ≥ 8% |
T6 | ≥ 205Mpa | ≥ 180Mpa | ≥ 8% |
6061 | T6 | ≥ 265Mpa | ≥ 245Mpa | ≥ 8% |
Competitive Advantage:
1)Engineering design and support.
2)Aluminum profiles deeply
processing:cutting,punching,drilling,milling,and fabricating.
3)High Quality system, strictly inspection during production and
whole inspection before package.
4)Good performance, product warranty for 15 years.
FAQ For Saving Your Precious Time!
Q1: What's the thickness for anodizing? Can you do 15um?
A: Our normal thickness is about 10 um. Yes, we can do 15um and
above.
Q2: What color you can do for powder coating? The thickness for powder
coat?
A: We can do any color for powder coat as long as you can provide
the color sample. Our normally powder coating thickness is 60-80um.
Q3: What's the delivery time for samples and mass production?
A: (1). 2-3 weeks to open the new moulds and make free samples.
(2). 3-4 weeks after receipt of deposit and confirmation of the
order.
Q4: What's your MOQ?
A: Normally speaking, it's 1 ton .
Q5: What's payment terms?
A: Usually by T/T, 30% deposit and the balance paid before
shipment.
Q6: What's the packing way?
A: Commonly we use plastic film and kraft paper, also we can make
as per customers' requirements.
