6005 Alloy Alodine Aluminum Heat Sink Extrusion Profiles With CNC Machining

Ask Lasest Price
Brand Name :	HENTEC
Certification :	CA ,CE
Payment Terms :	T/T ,L/C
Supply Ability :	100 000ton each month
Delivery Time :	20days

Add to Cart

Product Details
Company Profile

6005 Alloy Alodine Aluminum Heat Sink Extrusion Profiles With CNC Machining

6005 Alloy Alodine Aluminum Heat Sink Extrusion Profiles With CNC Machining

Advantage

1. We have our own factory and can provide products with good quality and competitive prices
2. Our products are exported to many countries and regions and have good reputation
3. Eco-friendly,safe,easy to use

Description :

(1). Aluminum anodized profile for heat sink
(2). 20 years warranty.
(3). High corrosion resistance.
(4). 5-10 years weather resistance.
(5). Good wear resistance & anti-scratch.
(6). Size customized.
(7). Alloy temper:6061-T6,6063-T5,6082-T6,6005-T5,etc.
(8). Standard: EN755, ASTMB221, DIN Standard
(9). Surface treatment: Mill finishes;Anodized; Powder coated;Wooden grain,Electrophoresis, Machine/Acid polished and etc.
(10). Applicant: industry, construction, exhibition, car, decoration and etc.
(11). Packing details:Shrinking film, Carton,Wooden pallet or By customer's requirements.
(12). Delivery: 25-30 days for mass production

Product Description
Item	Alodine Aluminum Heat Sink Extrusion Profiles With CNC Machining
Material	6063/6063A/6061
Temper	T3-T8
Size/Thickness	General aluminum profiles thickness from 0.7-4.0mm, length from 3m-6.4m or customized availble; Anodize protection Thickness from 8-18um, powder coating from 40-100um.
Shape	Customized, rectangual, round, square
Application	Machine , Led Light and so on
Suface treatment	Powdering coating
Colors	Anodize, powdering coating and customized availble
MOQ	500 kgs for each item
Packing Details	Packing with plastic protective film inside; Plastic film or craft paper outside
Delivery time	Developing and sample testing: 15-17 days; 2. Production completed: 25-30days after sample is comfirmed by customers
FOB Port	Shanghai
Payment	T/T, L/C
Settlement term	Final actual weight or theory weight
Production capacity	2000 tons monthly, 2400 tons annually
Cetificate and Standard	BV, ISO, SGS

Applications:

Aluminum heat sink is widely used on Machines , cars , lighter ...

Specifications:

1. Primary Technical Data

1)Chemical composition

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Impurity	Al
6063	0.2-0.6	0.35	0.1	0.1	0.45-0.9	0.1	0.1	0.1	0.15	Rest
6061	0.4-0.8	0.7	0.15-0.4	0.15	0.8-1.2	0.04-0.35	0.25	0.15	0.15	Rest
6060	0.3-0.6	0.1-0.3	0.1	0.1	0.35-0.6	-	0.15	0.1	0.15	Rest
6005	0.6-0.9	0.35	0.1	0.1	0.40-0.6	0.1	0.1	0.1	0.15	Rest

2) Mechanical property

Alloy	Temper	Tensile strength	Yield strength	Elongation
6063	T5	≥ 160Mpa	≥ 110Mpa	≥ 8%
6063	T6	≥ 205Mpa	≥ 180Mpa	≥ 8%
6061	T6	≥ 265Mpa	≥ 245Mpa	≥ 8%

Competitive Advantage:

1, This aluminum extraction profile for heat sink offers excellent engineering design and technical support .

2, With the deep processing ,it will be cut ,punched ,drilled ,milled and then fabricated into the finished product .

3, It is guaranteed on the excellent performance for as long as 15 years .

Tag :

extruded aluminum heat sink

aluminum heatsink extrusion profiles
