6063 - T6 Industrial Aluminium Profile For Assembly Stage /
Assembly Line
(1).Suitable for industry,architecture,transportation and so on.
(2).20 years warranty.
(3).High corrosion resistance.
(4).5-10 years weather resistance.
(5).Good wear resistance & anti-scratch.
(6).Size customized.
| Aolly | 6063 | 6061 | 6060 | 6005 | 6082 | | |
| Temper | T4 | T5 | T6 | | | | |
| Standard | DIN | AAMA | AS | CHINAGB | | | |
| Certification | ISO9001: 2008 |
| Surface Finish | Mill finish | Anodizing | Powder Coating | Wood Grain | Electrophoresis | Polished | Brushed |
| Color | Anodizing | Silver, bronze, champagne, titanium, nickel, golden yellow, etc. |
| Anodizing thickness is up to 25um |
| Powder Coating | White, black, bronze, grey, green, etc |
| Powder coating thickness is more than 60um |
| Electrophoresis | Silver, nickel, golden yellow, black, champagne, etc |
| Polishing | Silver, nickel, golden yellow, black, etc |
| Brushing | Silver, nickel, golden yellow, black, bronze, etc |
| Machining | Cutting, punching, drilling, bending, weld, mill, CNC, etc. |
| OEM customized aluminium profiles are available. |
Description :
1. Material: 6063,6061,6060,6005,6005A,etc.
2. Temper: T5 or T6
3. Finish: Mill finish, anodizing, powder coating, electrophoresis,
wooden transfer or pvdf/carbon-flouride coated, polishing,
brushing, sand blasting
4. Various colors: Silver, bronze, black, gold, blue,grey,
champagne, bright, etc.
5. Machining: Cutting, punching, drilling, tapping, milling,
bending, welding, CNC etc.
6. Various in styles and sizes:
A) Aluminum alloy bars: 6000 series, normal material such as
6063,6005,6061,6060, special materials such as 6082 etc.
B) Aluminum profiles:
---General aluminum profiles (various shapes of pipes/tubes,
angles, T or U shapes etc.)
--- Industrial aluminum profiles ( TV frames, Rim for bicycles and
motorcycles, Heat sink profiles, Furniture, Ladder, Guide Rail,
Leisure materials, Shower Room, Solar Module Frame, Motor Shell,
Pipeline Integration etc.)
--- Construction aluminum profiles ( Aluminum doors& windows,
Sliding Windows, JB50A Door Window, Curtain Wall Frame etc.)
7. Certification: ISO9001,SGS,ROHS,TUV
8. Strong technical development ability, can provide high intensity
and high ductility aluminum profiles, to meet customers' different
requirements.
9. OEM service available, customized design available
10. Surface available: Mill finish, Anodized, Powder Coating,
Wooden transfering, electrophoresis, heat insulation, PVDF, and
deep processing
11. Certificate: ISO9001, ISO14001
Applications:
Industry Aluminum profile used in cars, trains machinery
,electronics, medical and other industrial filed . In terms of
hardware, machinery, electromechanical parts, solar PV products,
aluminum frames are adopt as important auxiliary materials. We also
have aluminum profiles for radiators, fitness machinery, buildings,
lighting instrument, windpipes, oil pipelines, for instance.
Specifications:
1.Primary Technical Data
1)Chemical composition
Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Impurity | Al |
6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45-0.9 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | 0.25 | 0.15 | 0.15 | Rest |
6060 | 0.3-0.6 | 0.1-0.3 | 0.1 | 0.1 | 0.35-0.6 | - | 0.15 | 0.1 | 0.15 | Rest |
6005 | 0.6-0.9 | 0.35 | 0.1 | 0.1 | 0.40-0.6 | 0.1 | 0.1 | 0.1 | 0.15 | Rest |
2)Mechanical property
Alloy | Temper | Tensile strength | Yield strength | Elongation |
6063 | T5 | ≥ 160Mpa | ≥ 110Mpa | ≥ 8% |
T6 | ≥ 205Mpa | ≥ 180Mpa | ≥ 8% |
6061 | T6 | ≥ 265Mpa | ≥ 245Mpa | ≥ 8% |
Competitive Advantage:
1)Engineering design and support.
2)Aluminum profiles deeply
processing:cutting,punching,drilling,milling,and fabricating.
3)High Quality system, strictly inspection during production and
whole inspection before package.
4)Good performance, product warranty for 15 years.
